0.2-50um Pore Size Kieselguhr Filter For Carbonated Beverage Processing
| Place of Origin | Shanghai, China |
|---|---|
| Brand Name | RUNLAN |
| Model Number | RLKF-12000 |
| Minimum Order Quantity | 1 |
| Price | $2,686.00/sets 1-2 sets |
| Packaging Details | Plywood Case |
| Supply Ability | 20 Set/Sets per Month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Processing | Filter | Showroom Location | Russia, Australia |
|---|---|---|---|
| Video Outgoing-inspection | Provided | Machinery Test Report | Provided |
| Marketing Type | Hot Product 2024 | Warranty Of Core Components | 1 Year |
| Core Components | Pressure Vessel | Condition | New |
| Processing Types | Carbonated Beverage | Voltage | 220V/380V |
| Power | 0.55KW | Weight | 120 KG |
| Dimension(L*W*H) | 1000*1000*2000 Mm | Warranty | 1 Year |
| After-sales Service Provided | Engineers Available To Service Machinery Overseas | Material | SS304/SS316L |
| Filter Type | Diatomite Flter | Pore Size | 0.2-50um |
| Pump | 380V/3Phases/50HZ | Design Pressure | 1.0Mpa |
| Working Pressure | 0.6Mpa | Scope Of Application | Wine/food Liquid |
| Filter Media | Filter Cartridges | Surface Treatment | Mirror Polish |
Product Description
Carbonated Beverage Processing Types wine filter machine Kieselguhr Filter specification:
This machine is semi automatic kieselguhr filer, widely used in food, medical and chemical industry.
For example, fruit juice, gape wine, alcohol wine, vinegar and others.
After filtering, the material is better in quality and taste.
Different structural principle, diatomite filter is divided into pole diatomite filter and frame diatomite diatomaceous earth
filter,but using the same principles and methods of operation, contains mixed earthenware jars , soil pump and automatic control
systems, the machine can be intermittent filtration, and cake will not fall off, to arrange production schedule and power fault is
not a problem; Have a special residual liquid discharge pipeline, filtrate losses can be minimum; The selection of foreign
technology for the diaphragm metering pump metering pump, with a simple structure, measurement precision, and can be filtrate
turbidity at any time adjust the amount of diatomaceous earth filter aid added, the use of automatic control of cleaning waste
diatomaceous earth emissions, water saving;
Including: diatomite filter, membrane filter, plate and frame filter; Beer filtration systems include two types: diatomite filter
machine and membrane filter.
Carbonated Beverage Processing Types wine filter machine Kieselguhr Filter advantages:
1. All the parts of the filter are compact,fixed in four wheels.two self-locking ,wheels can de ensure good stability.
2. Complete construction is made of stainless steel 304.
3. The addition of the kieselguhr is regulated by the piston pump.
4. Inlet and outlet fittings with illuminated sight glasses.
5. Horizintal screens made of stainless steel 304 Reps type assure a better stability of the cake.
6. Bottom filtering element allows you totally recover the residual liquid at the end of the filtration.
7. The spray pipe in the filter elements assures easy and fast cleaning period with minimum water consumption.
8. In models 3,4,5,and 6 square meters,the fillter system is made by heavy duty shock adsorbers and the filtering bell runs on an
idoneus axe.
9. On request we fournish filter idoneus for sparkling wines,vinegar,beer,fruit juices and all feeding industry in general.
This machine is semi automatic kieselguhr filer, widely used in food, medical and chemical industry.
For example, fruit juice, gape wine, alcohol wine, vinegar and others.
After filtering, the material is better in quality and taste.
Different structural principle, diatomite filter is divided into pole diatomite filter and frame diatomite diatomaceous earth
filter,but using the same principles and methods of operation, contains mixed earthenware jars , soil pump and automatic control
systems, the machine can be intermittent filtration, and cake will not fall off, to arrange production schedule and power fault is
not a problem; Have a special residual liquid discharge pipeline, filtrate losses can be minimum; The selection of foreign
technology for the diaphragm metering pump metering pump, with a simple structure, measurement precision, and can be filtrate
turbidity at any time adjust the amount of diatomaceous earth filter aid added, the use of automatic control of cleaning waste
diatomaceous earth emissions, water saving;
Including: diatomite filter, membrane filter, plate and frame filter; Beer filtration systems include two types: diatomite filter
machine and membrane filter.
Carbonated Beverage Processing Types wine filter machine Kieselguhr Filter advantages:
1. All the parts of the filter are compact,fixed in four wheels.two self-locking ,wheels can de ensure good stability.
2. Complete construction is made of stainless steel 304.
3. The addition of the kieselguhr is regulated by the piston pump.
4. Inlet and outlet fittings with illuminated sight glasses.
5. Horizintal screens made of stainless steel 304 Reps type assure a better stability of the cake.
6. Bottom filtering element allows you totally recover the residual liquid at the end of the filtration.
7. The spray pipe in the filter elements assures easy and fast cleaning period with minimum water consumption.
8. In models 3,4,5,and 6 square meters,the fillter system is made by heavy duty shock adsorbers and the filtering bell runs on an
idoneus axe.
9. On request we fournish filter idoneus for sparkling wines,vinegar,beer,fruit juices and all feeding industry in general.
|
Model
|
Output (L/H)
|
Power Max (kw)
|
Length (mm)
|
width (mm)
|
Height (mm)
|
Filter surface (m2)
|
|
RLKF-4000
|
4000
|
1.75
|
1400
|
800
|
1400
|
2
|
|
RLKF-6000
|
6000
|
2.5
|
1400
|
800
|
1600
|
3
|
|
RLKF-8000
|
8000
|
2.5
|
1400
|
800
|
1950
|
4
|
|
RLKF-10000
|
10000
|
3.25
|
1750
|
1000
|
1890
|
5
|
|
RLKF-12000
|
12000
|
5.75
|
1000
|
1000
|
2000
|
6
|
