20KG Weight Stainless Steel Basket Filter for Food Shop Performance
| Place of Origin | Shanghai, China |
|---|---|
| Brand Name | RUNLAN |
| Minimum Order Quantity | 1 |
| Price | $100.00 - $1,000.00/sets |
| Packaging Details | Plywood Case |
| Supply Ability | 10000 Set/Sets per Month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Applicable Industries | Food & Beverage Factory, Food Shop, Energy & Mining, Food & Beverage Shops | Weight (KG) | 20 |
|---|---|---|---|
| Showroom Location | Russia, Australia | Video Outgoing-inspection | Provided |
| Machinery Test Report | Provided | Marketing Type | Ordinary Product |
| Warranty Of Core Components | 1 Year | Core Components | Pressure Vessel, Pump |
| Warranty | 1 Year | After-sales Service Provided | Engineers Available To Service Machinery Overseas |
| Port | Shanghai |
Product Description
filters
Stainless Steel Basket Filter specification:
Standard:ASME Code
Vessel Material: Carbon Steel, Stainless Steel
Filter Element Material: S S square mesh screen, spiral wound pipe, perforated plate, etc.
Element Strength:> 1Mpa
Vessel Diameter: <1200mm
Filter Precision: 50~2000microns
Basket type filter a small equipment which is used to remove small amount of solid particles in water,which consists of connecting pipe,main pipe,filtration basket,flange,blind flange and fastener,etc.When the liquid flows into the filtration basket through main pipe.solid impurity particles are blocked in the filtration basket,but the clean liquid will flow through the basket and be discharged through sewage outfall.when it needs to be cleaned,unscrew the bottom plug of main pipe,discharge the liquid and disassemble the blind flange,and assembly it again after cleaning.so it is easy to operate and maintain.
Stainless Steel Basket Filter advantages:
1. high efficient
2. power-effective
It is used filter impurities. According to your requirement, we can supply you the exact products.
It is a nonstandard article. Hence, further understanding will lead further cooperation.
If you have further interest, please let us know.
Stainless Steel Basket Filter Features:
- Divided into two types, i.e., with jacket or without jacket.
- The materials of filter can be designed according to the needs of customers.
- Its outer surface is treatment by shot blastign or polishing, beautiful & elegant, while its welding seam is treated of acid cleaning and passivation, so as to increase its anti-corrosion capacity.
- The relative position of inlet/outlet and installation height can be customized to suit the specific requirements of applications.
Main Technological Parameters:
| DN(mm) | D | H1 | H2 | L | b | Filtration area cm2 |
| DN100 | 273 | 250 | 480 | 600 | R1/2" | 2611 |
| DN150 | 325 | 350 | 700 | 850 | R3/4" | 4750 |
| DN200 | 426 | 500 | 900 | 1100 | R1“ | 8705 |
| DN250 | 580 | 600 | 1000 | 1250 | R1“ | 12759 |
| DN300 | 630 | 700 | 1150 | 1450 | R1“ | 16258 |
Our Service/ company:
Shanghai Runlan filtration equipment Co., Ltd. is a professional engaged in research, design , manufacture and sales of filtration equipment for the integration of Science & Technology entities of private joint-stock enterprise which founded in 2008. Registered capital of 3 million , 120 employees , annual turnover ( RMB ) 50 million. 2010 successfully registered "Run –Lan " trademark has become well-known brand in the industry.
