8-1480m3 Flow Rate Single Bag Plate Type Liquid Filter made of Stainless Steel 304/316

Place of Origin Shanghai, China
Brand Name Runlan
Minimum Order Quantity 1
Price $480.00/sets 1-2 sets
Packaging Details Plywood Case
Supply Ability 10000 Set/Sets per Month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Condition New Applicable Industries Manufacturing Plant, Food & Beverage Factory, Other
Weight (KG) 25 Showroom Location Egypt, United States, Russia, UAE, Kazakhstan, Malaysia, Australia
Video Outgoing-inspection Provided Machinery Test Report Provided
Marketing Type Hot Sales Product Warranty Of Core Components 12 Months
Core Components Pressure Vessel Warranty 12 Months, 12 Months
Product Name Stainless Steel 304/316 Filter Housing Type Liquid Filter
Connection Screw Thread/Flanged Seal Type BUNA,Silicone,Viton
Filter Media Filter Bags Shape Cylinder Shape
Flow Rate 8-1480m³ Micron Rating 1~100micron
Material Stainless Steel 304 316 316L
Leave a Message
Product Description
Product Description
8-1480m3 Flow Rate Single Bag Plate Type Liquid Filter made of Stainless Steel 304/316 0

Material: SUS304, SUS316L
Connection type: screw thread or flange
Seal material: BUNA/Silicone/Viton
Seal type: O-type seal ring
Apply to a strainer: 1#/2#/3#/4# filter bag
Design pressure: 1.0Mpa
Design flow: 6-40m3/H
Surface disposal: Sandblast or electrolytic polishing
Side entrance design
Mounting legs with adjustable geight

Features
◆ High capacity, small size ◆ Easy to replace the filter bag, no need clean and labor saving ◆ After cleaning the filter bag can be used repeatedly to save cost ◆ Lower leakage risk ensures high quality ◆ Wide application, flexible use, various installation model for choice ◆ High working pressure, low pressure loss, low operation cost and energy saving
Specification
item
value
Condition
New
Applicable Industries
Manufacturing Plant, Food & Beverage Factory, Other
Weight (KG)
25
Showroom Location
Egypt, United States, Russia, UAE, Kazakhstan, Malaysia, Australia
Video outgoing-inspection
Provided
Machinery Test Report
Provided
Marketing Type
hot sales product
Warranty of core components
12 months
Core Components
Pressure vessel
Place of Origin
China
Shanghai
Brand Name
Runlan
Warranty
12 months
Product name
stainless steel 304/316 filter housing
Type
Liquid Filter
Connection
Screw thread/Flanged
Seal type
BUNA,Silicone,Viton
Filter media
filter bags
Shape
Cylinder Shape
Flow rate
8-1480m³
Micron Rating
1~100micron
Material
Stainless Steel 304 316 316L
Warranty
12 months
Applicable industry
8-1480m3 Flow Rate Single Bag Plate Type Liquid Filter made of Stainless Steel 304/316 1
Certifications
8-1480m3 Flow Rate Single Bag Plate Type Liquid Filter made of Stainless Steel 304/316 2
Packing & Delivery
8-1480m3 Flow Rate Single Bag Plate Type Liquid Filter made of Stainless Steel 304/316 3
Company Profile
8-1480m3 Flow Rate Single Bag Plate Type Liquid Filter made of Stainless Steel 304/316 4
8-1480m3 Flow Rate Single Bag Plate Type Liquid Filter made of Stainless Steel 304/316 5
8-1480m3 Flow Rate Single Bag Plate Type Liquid Filter made of Stainless Steel 304/316 6
8-1480m3 Flow Rate Single Bag Plate Type Liquid Filter made of Stainless Steel 304/316 7
8-1480m3 Flow Rate Single Bag Plate Type Liquid Filter made of Stainless Steel 304/316 8
FAQ
8-1480m3 Flow Rate Single Bag Plate Type Liquid Filter made of Stainless Steel 304/316 9
